New Business Field
High-Functional MaterialsPorous Polyimide Film
Unique and Uniformed pore structure
Unique and Uniformed pore structure
Features
- Open cell structure of spherical pores
- Extremely narrow pore size distribution
- High porosity (～80%)
- Low dielectric constant
- Thickness (10～100μm)
Applications
- Membrane for high efficiency removal
- Low dielectric material for high frequency printed circuit board
- Thermal insulation material
Film Performance
| Item | Unit | μm Pore | nm Pore | |
|---|---|---|---|---|
| Prosity | % | 70 | 70 | |
| Gurley | sec/100cc | 8～10 | 200～300 | |
| Strength | MPa | 25～35 | 25～40 | |
| Elongation | % | 20～25 | 20～40 | |
| Thermal decomposition | ℃ | 571 | 571 | |
| Dielectric | 1 GHz | ― | ― | 1.495 |
| 10 GHz | ― | 1.461 | ||
Product Inquiry
If you have any inquiries about this product, please click the button below. Our representative will contact you by return.
